High Quality Stereo Car Stereo Fast Charger High Power Density Non Polar High Voltage Capacitor Y5T-101K-15KV

Category: Tag:

Description

High Quality Stereo Car Stereo Fast Charger High Power Density Non Polar High Voltage Capacitor Y5T-101K-15KV

Non Polar High Voltage Capacitor

Cucab Capacitor Parameters

Specification Reference Standard

GB/T?2693-2001 ;?GB/T?5966-1996??

Rated Voltage(UR)

500?/?1K?/?2K?/?3K?/?4K?/ 5K?/?6K?/ 7K / 8K / 9K / 10K?/ 15K / 20K / 25K /?30K / 40K /50K?VDC

Capacitance Range

1pF to 100000pF

Voltage?Proof

 <500V,2.5UR?;?≥500V≤3KV,1.5UR+500V ; >3KV,1.2UR

Capacitance Tolerance

 NPO±0.5pF(D)±5%(J)?;?SL±5%(J)±10%(K),Y5P,Y5U±10%(K )?;?Y5U,Y5V±20%(M)

Dissipation?Factor (tgδ)

 C<30pF,Q≥400+20C ; C≥30pF,Q≥1000?,Y5P,Y5U,Y5V:tgδ≤2.0% ; Y5P(Low loss type):tgδ≤0.5% ; Y5R:tgδ≤0.3%

Insulation?Resistance(IR)

IR≥10000MΩ,1min,100VDC,IR≥4000MΩ,1min,100VDC

Operating Temperature

-25℃ to +85℃

Temperature Characteristic

NPO,SL,Y5P,Y5U,Y5V

Flame?Retardant?Epoxy

UL94-V0

Non Polar High Voltage Capacitor

Non Polar High Voltage Capacitor

Non Polar High Voltage Capacitor

2.7V 3000F Super Capacitor

Cucab Capacitor Application

14D270K Epoxy Resin Film Zinc Oxide Varistor

Cucab Equipments

2.7V 3000F Super Capacitor

About Cucab

? ? Cucab Capacitor is a manufacturer of capacitors with well-equipped testing equipment and strong technical force. So far, we have been in this business for over 18 years.With abundant experience including excellent manufacturing experience, good management and easy delivery in the domestic market, provide customers with high quality products. In order to improve our competitive ability internationally, we have added many new automatic production equipment and testing instruments, including ceramic chip production line and AC safety capacitor. Our production process ranges from material agglomeration to product processing. In addition, we develop products as per customers’ requirements with advanced technology.Our AC safety capacitors have obtained authorized certificates like CSA, UL and VDE, which are recognized by eight countries, such as Switzerland, Finland, Norway, Sweden and Denmark. Also, we have received CQC certificate issued by China Quality Authentication Center.
Therefore, we make our products and company system perfect for supplying excellent service to customers from all over the world.We adhere to the principle of “Sincerity and High quality” and the pursuit of scientific management. At present, our main products are high potential condensers from 500V to 50KV and AC safety capacitors. Based on the idea of “Quality and Customer come first, forever management”, we also have ISO9001:2015 certificate by all our staff members’ hard work. All of our staff members are continuously improving technique, quality and service to meet the coming requirements from customers all over the world.We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!

Cucab Capacitor Factory

Cucab Capacitor Factory

Cucab Capacitor Factory

Cucab Partners

Cucab Shipping & Packing

Capacitor Warehouse

Cucab Capacitor YouTube Video

Additional information

Color

Blue

Cucab FAQ

A: It’s a combination of super capacitor and battery, which combines power density of super capacitors and energy density of batteries.

A: We are a professional manufacturer of super capacitor batteries. We promise all products are original and brand new.

A: Cells normally only take 1-3 days lead time; modules will take about 15-20 business days.

A: Under standard operating condition, we guarantee no less than 20,000 time life cycles.

A: OEM and ODM are both acceptable. Please contact us for more details.

A: We can provide CE,MSDS,UN38.3 etc.

A: YES, LOGO/sticker/OEM/ODM welcomed
